Electric charges and fields

 Electric Charges and Fields

  Problems

Question1. Two charges +10 μC and -10 μC are placed 5.00 mm apart. Determine the electric field at (a) a point P on the axis of the dipole 15 cm away from its centre O on the side of the positive charge, (b) a point Q, 15 cm away from O on a line passing through O and normal to the axis of the dipole.


 Question2. The force experienced by a unit charge when placed at a distance of 0.10 m from the middle of an electric dipole on its axial line is 0.025N and when it is placed at a distance of 0.2m, the force is reduced to 0.002N. Calculate the dipole length.
